LESER Safety Valves
The following product groups are preferred:
Compact Performance
High Performance
API
LESER recommends austenitic stainless steels such as the LESER standard materials 1.4404/316L or 1.4408/CF8M for wetted safety valve parts. These materials are insensitive to hydrogen embrittlement. Whether cast or forged material is to be used depends on the respective application conditions. LESER Safety Valves have proven their suitability for cryogenic temperatures from -150 °C/ -238 °F to absolute zero for years. For best sealing results under these conditions, the following product configuration is recommended:
Safety valve with nozzle – Product group API Type 5264
Metallic sealing surfaces - standard version
Stellited disc - LESER option code J25
Stellited nozzle - LESER option code L65
